Industrial Epoxy Mold Compounds

Industrial epoxy molding compounds are tough composites with excellent thermal shock and thermal cycle resistance. Their chemistry is well-suited for molding large parts, minimizing the potential for crack development while maintaining excellent color stability up to 180°C. Even though the vast majority of industrial EMC is reinforced with Fiberglass to provide additional toughness, there are also plain silica epoxies that provide great price/performance ratio for high voltage applications.

Fiberglass is not the only main characteristic of Industrial EMC. The choice the of curing agent or hardener is also an important aspect that give Epoxy Molding Compound very specific post cure material properties. In our case it is Anhydride that is used as the leading industrial EMC hardener. The definition of an anhydride is the compound obtained by removing the elements of water from a particular acid, an organic compound containing the group —C(O)OC(O)—, derived from a carboxylic acid.

Some of the unique benefits offered by anhydride cured epoxy molding compounds are low mix viscosities for long flow molding, excellent electrical insulation properties, low ionic movement at elevated temperatures that leads to very stable electrical properties at high temps and the very good temperature stability that leads to longer shelf and pot life. Those are on top of the already mentioned excellent mechanical and thermal properties

Compare Products
10 products
Compare Products
10 products

Product Selector Guide

Industrial Epoxy Molding Compounds - No longer available from CAPLINQ
Product Name Properties Comments
Specific
Gravity
Glass Transition
Temperature (Tg), °C
CTE, Alpha 1
ppm/°C
CTE, Alpha 2
ppm/°C
Flexural Modulus
@25°C
GPa
Flexural Strength
@25°C
MPa
Spiral Flow
@150°C
inches
Gel Time
@160°C
seconds
MG6-0330 1.86 105 TBD TBD 13.8 138 15 28 Bushing and high voltage applications requiring excellent electrical insulation and large mold shot (up to 5kg)
MG33-0690 - 165 19 55 15.2 131 - -  Halogen-Free epoxy molding compounds for High Power Applications
MH6-0504 2.15 140 42 118 13.5 148 30 22 Solenoid coils (coil winded fluid valves), power/ current transformer, relays, switches
MH6-0508NF 1.93 TBD TBD TBD TBD TBD - - "NF" signifies it is a non-flameout version (per UL94-V0) of MH6-0504
MH6-0510 - 140 41 112 14.6 145 - - Green color version of MH6-0504 Black
MH20-01 1.86 161 31 71 13.8 145 55 35 Very tough epoxy mold compound with excellent high temperature resistance. Gold version exists.
MH20-01 IM 1.86 144 32 75 15.2 134 40 22 Injection moldable version of MH20-01
MH20-0686 1.98 144 30 88 15.2 - 18   Excellent high temperature stability. Up to 225C operating. Short Flow Version of MH20-01. Uses an EPN.
MH20-2000 1.86 140 17 50 6.76 148 - - MH20-2000 has nearly the same strength as steel, but is much lighter.

Frequently Asked Questions

Don\'t anhydride-cured epoxies have a low Tg?

Not anymore. It has historically been true that anhydride-cured epoxies had a glass transition temperature (Tg) that was lower than 150°C. Modern-day epoxies using an ahydride curing agent can have Tgs above 200°C.

Are there any downsides to anhydride curing agents?

Yes. The biggest downside to anhydride-cured epoxies these days is the high moisture absorption during cure. Epoxy cresol novolacs and other phenolic-based curing agents have moisture absorptions that are lower than those obtained with anhydrides. For large devices requiring high MSL performance, this can be an issue, but for discrete through hole devices, this should be no problem at all.

Is there only one anhydride curing agent?

No. there is a wide range of anhydrides one can choose from, and the industry is always developing new types. Among these choices are:

  • Aromatic anhydrides
  • Alicyclic anhydrides
  • Aliphatic anhydrides

Each of which offer further unique material properties.

What are the main EMC ingredients?

Epoxy Molding Compounds basic building blocks are made of the following ingredients:

  • Epoxy Resin
  • Epoxy Curing Agent (often referred to as Epoxy Hardener)
  • Catalyst
  • Filler
  • Pigment
  • Additives

Learn More

In a world of  stringent environmental controls and ever hotter operating temperatures, epoxy mold compounds are getting a bad reputation. This reputation is not only misplaced, it often misses the point completely.

Anhydride curing agents are some of epoxies oldest curing agents, and probably the most widely used curing agent in epoxy molding compounds’ 75+ year history. This is not a coincidence. Although epoxy molding compound chemistry has evolved over these same 75 years into novolacs, phenolics, bismaleimides, and multi-aromatic resins, anhydride chemistry still holds an important place not only in history but also in the future as. This section will concede that the use of anhydride epoxy mold compounds may be sunsetting for some applications, but it is still the best choice for a wide range of other applications.

In order to talk about the future of anhydride chemistries, it’s important to highlight, discuss and debunk some known myths about anhydrides

  1. Anhydrides contain ingredients on the SVHC list
  2. Anhydrides cannot be used in higher-temperature applications
  3. Anhydrides tend to have higher moisture absorption than other chemistries
  4. Anhydrides have CTE’s that are too high for modern-day applications



Concern 1: Anhydride chemistry contains ingredients on the SVHC list

The Substances of Very High Concern or SVHC list is a list of chemicals (substances) created by the European CHemicals Agency (ECHA) to record substances that have been tested deemed to be either:

  • Persistent, bioaccumulative and toxic
  • Toxic for reproduction or
  • Carcinogenic (cancer causing)

Since 2012, only two anhydrides have made it on this list, and since there are many different types and formulations of anhydrides to choose from, these two hardly make up the majority of anhydride formulations available to use in an epoxy mold compound formulation.

Furthermore, new developments and research have identified many new types of anhydride formulations that are quite different than the older anhydrides and aren’t expected to ever make it onto the ECHA SVHC list.

This said, it’s important to point out that anhydrides are hardly a black sheep in this respect. Not using anhydrides in epoxy mold compound formulations does not preclude it from having substances that will end up on the SVHC list. Many other types of epoxy formulation chemistries, including multi-aromatic resins, bismaleimides, novolacs, and phenolics have used substances that have found their way onto the SVHC list.



Concern 2: Anhydrides cannot be used in higher temperature applications

Let’s define “higher temperature applications”. While yes, it is true that automotive applications see a trend to temperatures that approach 220°C or even 250°C over the next 10-15 years, these are still upper END temperatures of such applications. The majority of applications that use epoxy mold compounds still see 180°C as a value well above the application operating temperature.

Table 1. UL-Approved Electrical Insulation system (EIS) Class
Maximum
temperature at hottest spot
UL 1446
temperature classes
IEC85 temperature classes
130°C (266°F) B B
155°C (311°F) F F
180°C (356°F) H H
200°C (392°F) N 200
220°C (428°F) R 220
240°C (464°F) S 250
over 240°C (over 464°F) >240°C *
*Above 250°C, each class is a temperature of 25°C higher than the preceding one. (ie. 275, 300, etc.)



To add insult to injury, engineers often mistake a material’s glass transition temperature (Tg) for its maximum operating temperature. While it is true that a materials’ physical properties - including its coefficient of thermal expansion (CTE) and Flexural Modulus (E) – do change at a material’s Tg, these are not signs of material degradation. In many cases, these properties go through a perfect hysteresis meaning that the material’s original CTE and modulus are reverted once the temperature is returned below its Tg.

But don’t take our word for it, the proof is in the pudding as they say. The Underwriter’s Laboratory (UL) has designed a UL-Approved Electrical Insulation system (EIS) class which are based on the maximum "hot spot" in the system. (See Table 1) . Manufacturers have been formulating two anhydride chemistries, MH6-0504 and MH6-0510 for over forty years that are in use on applications that have a Class H rating, meaning they can be used in applications that can see temperatures up to 180°C.

In addition to this, though anhydride chemistries may not be able to achieve the same higher maximum electrical insulation class (Class N) as some of its novolac counterparts, the temperatures at which it is stable (up to 180C), it is very stable. As you can see in Figure 1 below, tests were carried out with a “green color” version of epoxy molding compounds in both an anhydride chemistry and a novolac chemistry. The green colored novolac chemistry candidate showed a much worse temperature stability than the same color mold compound using an anhydride chemistry.

Anhydride chemistry is much more color stable at 180°C then novolac chemistryFigure 1: Anhydride chemistry is much more color stable at 180°C then novolac chemistry


Concern 3: Anhydrides have a higher moisture absorption than other chemistries

Moisture absorption tests measure the amount of moisture that epoxy mold compounds absorb after post mold curing and exposed to high moisture environments. Three standard tests for this include:

  • 1 hour water boil @ 100°C
  • 24 hour water soak @ 23°C
  • 168 hour moisture exposure at 85°C and 85% relative humidity (RH)

In all three of these tests, anhydride chemistries have a distinct disadvantage against other epoxy mold compound chemistries. They all reveal that the moisture absorption of anhydride chemistries is greater than their counterparts. So why does this matter to us?

A significant amount of epoxy mold compounds are used in the manufacture of semiconductor devices. In semiconductor applications, epoxy is used to encapsulate the semiconductor chip, thus providing both mechanical and environmental protection.

Early in the development of epoxy mold compounds for semiconductors, Joint Electron Device Engineering Council (JEDEC), an independent semiconductor engineering trade organization and standardization body, developed a series of moisture sensitivity level (MSL) tests that correlated the MSL level of semiconductor devices to the floor life of these same devices before these same devices needed to be “prebaked” again. See Table 2.

“Prebaking” is a process in the printed circuit board (PCB) assembly process that literally bakes the semiconductor devices in an oven for 24 hours @ 100°C to drive out moisture that may have accumulated in the device as the device sat on the production floor waiting to be mounted onto the printed circuit board. Because the printed circuit board process always involves the soldering of components onto the PCB in a solder reflow oven, a process that exposes the PCB and all its components to temperatures up to 260°C for up to 10 minutes, it is critical that all the components can withstand this temperature cycle.

What was discovered was that in the absence of this prebaking step, semiconductor devices that contained too much moisture would fail catastrophically during this reflow step as moisture trapped within the epoxy mold compound would expand and cause delamination from the semiconductor device, break critical wirebonds and separate from the leadframe in a process now coined “popcorning”.



Table 2. JEDEC Moisture Sensitivity Level (MSL)
 Level Floor Life Soak Requirements
Standard Accelerated
- Time Condition
°C/%RH
Time (hrs) Cond
°C/%RH
Time (hrs) Condition
°C/%RH
1 unlimited <=30°C/85%RH 168+5/-0 85°C/85%RH n/a n/a
2 1 year <=30°C/60%RH 168+5/-0 85°C/60%RH n/a n/a
2a 4 weeks <=30°C/60%RH 696+5/-0 30°C/60%RH 120+1/-0 60°C/60%RH
3 168 hours <=30°C/60%RH 192+5/-0 30°C/60%RH 40+1/-0 60°C/60%RH
4 72 hours <=30°C/60%RH 96+2/-0 30°C/60%RH 20+0.5/-0 60°C/60%RH
5 48 hours <=30°C/60%RH 72+2/-0 30°C/60%RH 15+0.5/-0 60°C/60%RH
5a 24 hours <=30°C/60%RH 48+2/-0 30°C/60%RH 10+0.5/-0 60°C/60%RH
6 TOL <=30°C/60%RH TOL 30°C/60%RH n/a 60°C/60%RH
  1. TOL means \'Time on Label\', or the time indicated on the label of the packing.
  2. The standard soak time is the sum of the default value of 24H for the semiconductor manufacturer\'s exposure time (MET) between bake and bag and the floor life or maximum time allowed out of the bag at the end user or distributor\'s facility. For example, an MSL 3 package will require a standard soak time of 192 hours, which is 168 hours of floor life plus 24 hours between bake and bag at the semiconductor manufacturer.



MSL tests are very useful for PCB manufacturers as it gives them a common guideline they can adopt for their semiconductor device suppliers. For epoxy mold compound manufacturers, on the other hand, the criteria is more abstract as the semiconductor devices range wildly in size, shape, and materials used. There are literally thousands of different combinations when one considers all the potential variables – a number that has only increased in modern times as devices types and materials continue to evolve.

Fortunately for epoxy mold compound manufacturers, there are three main material properties that will indicate whether an encapsulant will have better MSL performance than its predecessor or competitor:

  • Higher adhesion to the given substrates
  • A matched coefficient of thermal expansion (CTE)
  • A lower moisture absorption

A higher adhesion to the substrate is logical as an unbroken bond will not fail, and the matched CTE will be discussed more in the next section, but the last point brings us full circle on our discussion of the importance of low moisture absorption.

So what happens if there is no high-temperature solder reflow step, as there weren’t in discrete, through-hole components or in other, non-semiconductor applications? Then moisture absorption values become less relevant, and the whole concern over “higher moisture absorption” of anhydride chemistries no longer holds water, as a humorous chemist may say.



Concern 4: Anhydrides’ CTE’s are too high for modern-day applications

As explained in the section above, it is important for semiconductor device manufacturers using epoxy molding compounds to select encapsulants that “match” the coefficient of thermal expansion of their leadframes and substrates. Refer to Table 3 for the list of typical material used in the semiconductor industry.

Table 3. CTE of Common substrates
Materials Coefficient of Thermal Expansion (CTE), ppm/°C
 Silicon  3 ppm/°C
Ceramic   6.7 ppm/°C
 Al2O3*   7-8 ppm/°C
 FR4 Laminate   14-17 ppm/°C
Copper (Cu)  17 ppm/°C
Silver (Ag)  18 ppm/°C
*High Thermal Conductivity Ceramic substrate for Direct Bond Copper (DBC) for Power Modules,

The reason this is so critical in semiconductor devices manufacturing is that the dimensions are so tiny (measured in microns and nanometers) and the stresses caused by the high-temperature solder reflow process are so high, that even the slightest CTE mismatch can cause catastrophic semiconductor device failure.

This phenomenon has only been exaggerated over the past decade as semiconductor devices have gotten even smaller, manufacturers have moved to even higher temperature reflow profiles to accommodate lead-free solders and PCB assemblers have insisted on ever-higher MSL performance.
